Product Details
- Interior powder coating is permanently bonded to the tank shell for ultimate protection on the water side of the water heater expansion tank
- Heavy duty butyl rubber diaphragm ensures long life
- Maximum working pressure 150 PSI
- Positive lock retention system controls compression in the diaphragm connection, eliminating air loss or water leaks in hot water expansion tank
- Corrosion-resistant metal air valve
- 5-year limited warranty on potable expansion tanks
American offers potable & hydronic expansion tank models, ranging from 2 to 10 gallons. American water heaters & accessories are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.
Specifications
Tech Specs
Nominal Gallon Capacity
2 Gallons
Rated Storage Volume
2 Gallons
Power Source
POTABLE EXPANSION
Limited Tank Warranty
5 Years
Limited Parts Warranty
0 Years
Water Connection Location
BOTTOM
Water Connection Size
3/4-in"
ASME Certified
No
Destination Country
US
Expansion Tank Application
Potable
Installation Type
INDOOR
Application
RESIDENTIAL
Shipping Height
13.75
Shipping Length
8.5
Shipping Width
8.5
Side Loop
No
Dimension & Venting
Type
Expansion Tank
Height
13.75"
Width
8.5"
Shipping Weight
5 lbs
